apply_tiles

Arguments:

• "command",_tile_width[%]>0,_tile_height[%]>0,_tile_depth[%]>0,_overlap_width[%]>=0,_overlap_height[%]>=0,_overlap_depth[%]>=0,_boundary_conditions={ 0:dirichlet | 1:neumann | 2:periodic | 3:mirror }

Description:

Apply specified command on each tile (neighborhood) of the selected images, eventually with overlapping tiles.

(equivalent to shortcut command at).

Default values:

tile_width=tile_height=tile_depth=10%,overlap_width=overlap_height=overlap_depth=0 and boundary_conditions=1.

Example of use:
