Images Have Edges: Now What?

images/image_edge.png r2dy 300Many G'MIC commands decide how to write an output pixel by accessing a neighborhood of input pixels, usually centered around the pixel in question. (See convolve, blur, deriche). In principle, the neighborhood may be arbitrarily large, in practice it is a ball or sphere just a few pixels across.

All this is well and good so long as we deal with images of infinite extent, but computer manufacturers behave badly when asked to provide such capacity, so as a practical matter, images have both finite extent and, therefore, edges. Difficulties arise with edges. At some point, a part of a neigborhood won't exist because the pixels are off an edge. How does one access a pixel that is not there?

In the absence of data, one often reaches for policy. G'MIC commands which need to worry about boundaries generally sport a boundary parameter which specifies up to four possible policies:

0dirichletOff-border pixels are considered a constant black. Named for Peter Gustav Lejeune Dirichlet. In particular, see Dirichlet Boundary Condition.
1neumannThe values of border pixels are presumed to extend infinity. Named for Carl Gottfried Neumann. In particular, see Neumann Boundary Condition.
2cyclicThe right hand border wraps to the left, the top to the bottom, so that pixels on the opposite edge neighbor each other. The image is a torus. See Periodic Boundary Conditions.
3mirrorThe value of virtual pixels past the border form a mirror image of the actual pixels approaching the border.

The flags 0, dirichlet, 1, neumann, 2 cyclic and 3 mirror are used consistently throughout G'MIC where the command in question performs some sort of operation entailing moving a kernel (a pixel and its neighborhood) over a surface, where it must, perforce eventually deal with edges and corners. These policies work well in some circumstances and poorly in others. There is no one 'right' approach; the choice usually depends on which set of limitations one can best live with. Many commands which operate on neighborhoods around input pixels do not fully implement the three policies; often the cyclic and mirror cases are omitted.
